Product Description
Custom Multi-Channel 50-Ohm BNC Cable Assembly
Organize multiple RF connections in one professional cable loom. This custom assembly combines individually shielded 50-ohm coaxial channels with secure BNC connectors and a rugged protective outer jacket for racks, facilities and portable systems.
Select RG-223 when enhanced dual-braid EMI/RFI protection is needed, or choose the available Belden 9201 RG-58/U construction for general-purpose 50-ohm RF applications. Available lengths and channel counts are shown in the product options above.
Every assembly is custom-built in the USA, clearly identified and tested before shipment.
Choose the Right Coax
Professional Multicore Features
- Multiple individually shielded 50-ohm coaxial channels
- BNC male connector configuration
- RG-223 or Belden 9201 cable options
- Protective braided outer jacket
- Numbered channels for fast identification
- Organized rack and field-system cabling
- Custom-built in the USA
- Every channel tested before shipment
- Lifetime Connector Replacement Warranty
Ideal Applications
- RF communications racks
- Wireless microphone antenna distribution
- Broadcast RF systems
- Laboratory test systems
- Telecommunications equipment
- Mobile and field systems
- Military and government installations
- OEM and system-integration projects
Technical Specifications
| Nominal Impedance | 50 Ohm |
|---|---|
| Cable Options | RG-223/U or Belden 9201 RG-58/U |
| Connector Type | BNC male |
| Channels and Lengths | Choose from the product options above |
| Outer Protection | Braided protective jacket |
| Identification | Numbered channels |
| Assembly | Custom-built in the USA |
| Testing | Every channel tested before shipment |
| Warranty | Lifetime Connector Replacement Warranty |
Why AV-Cables?
AV-Cables has supplied professional cable assemblies since 1995. Each RG-223 cable is assembled by experienced technicians in the USA and individually inspected and tested for dependable performance.
- Professional components and workmanship
- Custom lengths and volume production available
- Support for integrators, laboratories, government and OEM customers
- Lifetime Connector Replacement Warranty
Frequently Asked Questions
When should I choose RG-223?
Choose RG-223 when dual-braid shielding and enhanced EMI/RFI protection are important for the installation.
Can the channels carry SDI video?
No. These are 50-ohm RF channels. Professional SDI video requires 75-ohm coaxial cable and true 75-ohm connectors.
Are the channels individually identified?
Yes. Channels are numbered to simplify installation, troubleshooting and equipment changes.
Can AV-Cables build a nonstandard configuration?
Yes. Contact AV-Cables with the required cable type, length, channel count and fan-out details.
