Professional BNC Coaxial Cable Assemblies
AV-Cables manufactures professional BNC cable assemblies for broadcast video, SDI, RF, test equipment, word clock, CCTV and professional AV systems.
Choose precision 75-ohm BNC cables for video and digital signal applications or 50-ohm BNC cables for RF, communications and test equipment. Multiple coax constructions, lengths and connector configurations are available.
Choose Your BNC Cable Type
SDI BNC Cables Professional 6G-SDI and 12G-SDI cable assemblies for cameras, switchers, routers, monitors and broadcast video systems. Shop SDI BNC Cables → 75Ω RG59 BNC Cables 75-ohm RG59 coaxial cable assemblies for professional video, CCTV, monitoring and compatible 75-ohm equipment. Shop 75Ω RG59 BNC → 50Ω RG58 BNC Cables Professional 50-ohm coaxial assemblies for RF equipment, wireless systems, communications, test equipment and instrumentation. Shop RG58 BNC Cables → 50Ω RG223 BNC Cables Dual-shielded 50-ohm RG223 assemblies for professional RF, communications, test and equipment interconnect applications. Shop RG223 BNC Cables → 75Ω Word Clock BNC Cables Precision 75-ohm BNC cable assemblies for compatible digital-audio word clock and synchronization systems. Shop Word Clock Cables → BNC to RCA 75Ω Cables 75-ohm BNC-to-RCA coaxial assemblies for compatible professional video, monitoring and equipment-interface applications. Shop BNC to RCA Cables →
50 Ohm vs. 75 Ohm BNC Cables
BNC describes the connector style, but not every BNC cable has the same impedance. Matching the cable impedance to the connected equipment is important for maintaining the intended signal performance.
| Impedance | Typical Applications | Common AV-Cables Families |
|---|---|---|
| 75 Ohm | SDI video, broadcast video, CCTV, word clock and compatible 75-ohm video systems | 1855A, 4855R, 1505A, 4505R, 1694A, 4694R |
| 50 Ohm | RF, wireless, communications, test equipment and instrumentation | RG58 / Belden 9201 and RG223 |
BNC Cables for Professional Applications
- Broadcast cameras and monitors
- Video routers and switchers
- Production trucks and fly packs
- Studios and control rooms
- CCTV and security video systems
- RF and wireless equipment
- Test and measurement equipment
- Word clock synchronization
- Corporate and commercial AV
- Custom OEM and integration projects
Need a Different BNC Connector Configuration?
AV-Cables also manufactures specialized broadcast cable assemblies when standard BNC-to-BNC cables are not the right connection.
Why Choose AV-Cables?
- Professional cable assemblies hand-assembled in the USA
- Every completed cable individually tested before shipment
- Precision 50-ohm and 75-ohm BNC configurations
- Multiple coaxial cable constructions for different applications
- Standard and custom lengths available
- Custom assemblies for broadcast facilities, production companies, integrators, government and OEM applications
- Lifetime Connector Replacement Warranty on qualifying AV-Cables assemblies
BNC Cable Frequently Asked Questions
What is a BNC connector?
A BNC is a bayonet-style coaxial connector widely used on professional video, RF, test, communications and synchronization equipment.
Are all BNC cables 75 ohm?
No. BNC connections are commonly used with both 50-ohm and 75-ohm coaxial systems. The correct cable impedance depends on the connected equipment and application.
Should I use a 50-ohm or 75-ohm BNC cable?
Professional video, SDI and word clock systems commonly use 75-ohm coaxial connections, while many RF, wireless, communications and test-equipment applications use 50-ohm connections. Confirm the required impedance of your equipment before ordering.
What BNC cable should I use for SDI video?
Use a precision 75-ohm SDI cable rated for the required signal format and transmission distance. AV-Cables offers dedicated 6G-SDI and 12G-SDI BNC cable families for professional broadcast video systems.
Do you make custom BNC cables?
Yes. AV-Cables manufactures custom BNC assemblies in specialized lengths, cable constructions, connector configurations and production quantities.
Need Help Choosing a BNC Cable?
Tell us your equipment, signal type, required impedance, connector configuration and cable length. We can help identify the appropriate BNC assembly for your application.
